Chat Example
This guide demonstrates how to build a real-time chat application using Spring Boot Starter Actor without introducing third-party middleware.
Overview
The chat example shows how to:
- Build a real-time chat application using actors
- Implement WebSocket communication for real-time messaging
- Create a scalable, clustered chat system
- Eliminate the need for external message brokers or middleware
This example demonstrates how Spring Boot Starter Actor can be used to build real-world applications efficiently without relying on additional infrastructure components.
Source Code
You can find the complete source code for this example on GitHub: https://github.com/seonWKim/spring-boot-starter-actor/tree/main/example/chat
Key Components
ChatRoomActor
ChatRoomActor is a sharded actor that manages a chat room. Each chat room is a separate entity identified by a room ID. The actor maintains a list of connected users and broadcasts messages to all users in the room:
@Component
public class ChatRoomActor implements ShardedActor<ChatRoomActor.Command> {
public static final EntityTypeKey<Command> TYPE_KEY =
EntityTypeKey.create(Command.class, "ChatRoomActor");
/** Base interface for all commands that can be sent to the chat room actor. */
public interface Command extends JsonSerializable {}
/** Command to join a chat room. */
public static class JoinRoom implements Command {
public final String userId;
public final ActorRef<UserActor.Command> userRef;
@JsonCreator
public JoinRoom(
@JsonProperty("userId") String userId,
@JsonProperty("userRef") ActorRef<UserActor.Command> userRef) {
this.userId = userId;
this.userRef = userRef;
}
}
/** Command to leave a chat room. */
public static class LeaveRoom implements Command {
public final String userId;
@JsonCreator
public LeaveRoom(@JsonProperty("userId") String userId) {
this.userId = userId;
}
}
/** Command to send a message to the chat room. */
public static class SendMessage implements Command {
public final String userId;
public final String message;
@JsonCreator
public SendMessage(
@JsonProperty("userId") String userId, @JsonProperty("message") String message) {
this.userId = userId;
this.message = message;
}
}
@Override
public EntityTypeKey<Command> typeKey() {
return TYPE_KEY;
}
@Override
public Behavior<Command> create(EntityContext<Command> ctx) {
return Behaviors.setup(
context -> {
final String roomId = ctx.getEntityId();
return chatRoom(roomId, new HashMap<>());
});
}
/**
* Creates the behavior for a chat room with the given room ID and connected users.
*
* @param roomId The ID of the chat room
* @param connectedUsers Map of user IDs to their actor references
*
* @return The behavior for the chat room
*/
private Behavior<Command> chatRoom(
String roomId,
Map<String, ActorRef<UserActor.Command>> connectedUsers
) {
return Behaviors.receive(Command.class)
.onMessage(
JoinRoom.class,
msg -> {
// Add the user to the connected users
connectedUsers.put(msg.userId, msg.userRef);
// Notify all users that a new user has joined
UserActor.JoinRoomEvent joinRoomEvent = new UserActor.JoinRoomEvent(
msg.userId);
broadcastCommand(connectedUsers, joinRoomEvent);
return chatRoom(roomId, connectedUsers);
})
.onMessage(
LeaveRoom.class,
msg -> {
// Remove the user from connected users
ActorRef<UserActor.Command> userRef = connectedUsers.remove(msg.userId);
if (userRef != null) {
// Notify the user that they left the room
UserActor.LeaveRoomEvent leaveRoomEvent = new UserActor.LeaveRoomEvent(
msg.userId);
userRef.tell(leaveRoomEvent);
// Notify all remaining users that a user has left
broadcastCommand(connectedUsers, leaveRoomEvent);
}
return chatRoom(roomId, connectedUsers);
})
.onMessage(
SendMessage.class,
msg -> {
// Create a message received command
UserActor.SendMessageEvent receiveMessageCmd =
new UserActor.SendMessageEvent(msg.userId, msg.message);
// Broadcast the message to all connected users
broadcastCommand(connectedUsers, receiveMessageCmd);
return Behaviors.same();
})
.build();
}
/**
* Broadcasts a command to all connected users.
*
* @param connectedUsers Map of user IDs to their actor references
* @param command The command to broadcast
*/
private void broadcastCommand(Map<String, ActorRef<UserActor.Command>> connectedUsers,
UserActor.Command command) {
connectedUsers.values().forEach(userRef -> userRef.tell(command));
}
@Override
public ShardingMessageExtractor<ShardEnvelope<Command>, Command> extractor() {
return new DefaultShardingMessageExtractor<>(3);
}
}
UserActor
UserActor represents a connected user and handles sending messages to the user's WebSocket connection. It's implemented as a SpringActor that interacts with ChatRoomActor:
@Component
public class UserActor implements SpringActor<UserActor, UserActor.Command> {
public interface Command extends JsonSerializable {}
public static class Connect implements Command {
}
public static class JoinRoom implements Command {
private final String roomId;
public JoinRoom(String roomId) {this.roomId = roomId;}
}
public static class LeaveRoom implements Command {
public LeaveRoom() {}
}
public static class SendMessage implements Command {
private final String message;
public SendMessage(String message) {this.message = message;}
}
public static class JoinRoomEvent implements Command {
private final String userId;
public JoinRoomEvent(String userId) {this.userId = userId;}
}
public static class LeaveRoomEvent implements Command {
private final String userId;
public LeaveRoomEvent(String userId) {this.userId = userId;}
}
public static class SendMessageEvent implements Command {
private final String userId;
private final String message;
public SendMessageEvent(String userId, String message) {
this.userId = userId;
this.message = message;
}
}
public static class UserActorContext implements SpringActorContext {
private final SpringActorSystem actorSystem;
private final ObjectMapper objectMapper;
private final WebSocketSession session;
private final String userId;
public UserActorContext(SpringActorSystem actorSystem, ObjectMapper objectMapper, String userId,
WebSocketSession session) {
this.actorSystem = actorSystem;
this.objectMapper = objectMapper;
this.userId = userId;
this.session = session;
}
@Override
public String actorId() {
return userId;
}
}
@Override
public Behavior<Command> create(SpringActorContext actorContext) {
if (!(actorContext instanceof UserActorContext userActorContext)) {
throw new IllegalStateException("Must be UserActorContext");
}
return Behaviors.setup(
context -> new UserActorBehavior(
context,
userActorContext.actorSystem,
userActorContext.objectMapper,
userActorContext.userId,
userActorContext.session
).create()
);
}
public static class UserActorBehavior {
private final ActorContext<UserActor.Command> context;
private final SpringActorSystem actorSystem;
private final ObjectMapper objectMapper;
private final String userId;
private final WebSocketSession session;
@Nullable
private String currentRoomId;
public UserActorBehavior(ActorContext<Command> context, SpringActorSystem actorSystem,
ObjectMapper objectMapper, String userId, WebSocketSession session) {
this.context = context;
this.actorSystem = actorSystem;
this.objectMapper = objectMapper;
this.userId = userId;
this.session = session;
}
public Behavior<UserActor.Command> create() {
return Behaviors.receive(Command.class)
.onMessage(Connect.class, this::onConnect)
.onMessage(JoinRoom.class, this::onJoinRoom)
.onMessage(LeaveRoom.class, this::onLeaveRoom)
.onMessage(SendMessage.class, this::onSendMessage)
.onMessage(JoinRoomEvent.class, this::onJoinRoomEvent)
.onMessage(LeaveRoomEvent.class, this::onLeaveRoomEvent)
.onMessage(SendMessageEvent.class, this::onSendMessageEvent)
.build();
}
private Behavior<Command> onConnect(Connect connect) {
sendEvent(
"connected",
builder -> {
builder.put("userId", userId);
});
return Behaviors.same();
}
private Behavior<Command> onJoinRoom(JoinRoom command) {
currentRoomId = command.roomId;
final var roomActor = getRoomActor();
sendEvent(
"joined",
builder -> {
builder.put("roomId", currentRoomId);
});
roomActor.tell(new ChatRoomActor.JoinRoom(userId, context.getSelf()));
return Behaviors.same();
}
private Behavior<Command> onLeaveRoom(LeaveRoom command) {
if (currentRoomId == null) {
context.getLog().info("{} user has not joined any room.", userId);
return Behaviors.same();
}
sendEvent(
"left",
builder -> {
builder.put("roomId", currentRoomId);
});
final var roomActor = getRoomActor();
roomActor.tell(new ChatRoomActor.LeaveRoom(userId));
return Behaviors.same();
}
private Behavior<Command> onSendMessage(SendMessage command) {
if (currentRoomId == null) {
context.getLog().info("{} user has not joined any room.", userId);
return Behaviors.same();
}
final var roomActor = getRoomActor();
roomActor.tell(new ChatRoomActor.SendMessage(userId, command.message));
return Behaviors.same();
}
private Behavior<Command> onJoinRoomEvent(JoinRoomEvent event) {
sendEvent(
"user_joined",
builder -> {
builder.put("userId", event.userId);
builder.put("roomId", currentRoomId);
});
return Behaviors.same();
}
private Behavior<Command> onLeaveRoomEvent(LeaveRoomEvent event) {
sendEvent(
"user_left",
builder -> {
builder.put("userId", event.userId);
builder.put("roomId", currentRoomId);
});
return Behaviors.same();
}
private Behavior<Command> onSendMessageEvent(SendMessageEvent event) {
sendEvent(
"message",
builder -> {
builder.put("userId", event.userId);
builder.put("message", event.message);
builder.put("roomId", currentRoomId);
});
return Behaviors.same();
}
private SpringShardedActorRef<ChatRoomActor.Command> getRoomActor() {
return actorSystem.entityRef(ChatRoomActor.TYPE_KEY, currentRoomId);
}
private void sendEvent(String type, EventBuilder builder) {
try {
ObjectNode eventNode = objectMapper.createObjectNode();
eventNode.put("type", type);
builder.build(eventNode);
if (session.isOpen()) {
session.sendMessage(new TextMessage(objectMapper.writeValueAsString(eventNode)));
}
} catch (IOException e) {
context.getLog().error("Failed to send message to WebSocket", e);
}
}
@FunctionalInterface
private interface EventBuilder {
void build(ObjectNode node);
}
}
}
ChatWebSocketHandler
ChatWebSocketHandler handles WebSocket connections and messages:
@Component
public class ChatWebSocketHandler extends TextWebSocketHandler {
private final ObjectMapper objectMapper;
private final SpringActorSystem actorSystem;
private final ConcurrentMap<String, SpringActorRef<UserActor.Command>> userActors =
new ConcurrentHashMap<>();
public ChatWebSocketHandler(
ObjectMapper objectMapper, SpringActorSystem actorSystem) {
this.objectMapper = objectMapper;
this.actorSystem = actorSystem;
}
@Override
public void afterConnectionEstablished(WebSocketSession session) {
String userId = UUID.randomUUID().toString();
session.getAttributes().put("userId", userId);
UserActor.UserActorContext userActorContext =
new UserActor.UserActorContext(actorSystem, objectMapper, userId, session);
final SpringActorSpawnContext<UserActor, UserActor.Command> spawnContext =
new SpringActorSpawnContext.Builder<UserActor, UserActor.Command>()
.actorClass(UserActor.class)
.actorContext(userActorContext)
.build();
actorSystem.spawn(spawnContext)
.thenAccept(userActor -> {
userActors.put(userId, userActor);
userActor.tell(new Connect());
});
}
@Override
protected void handleTextMessage(WebSocketSession session, TextMessage message) throws Exception {
String userId = (String) session.getAttributes().get("userId");
JsonNode payload = objectMapper.readTree(message.getPayload());
String type = payload.get("type").asText();
switch (type) {
case "join":
handleJoinRoom(userId, payload);
break;
case "leave":
handleLeaveRoom(userId);
break;
case "message":
handleChatMessage(userId, payload);
break;
default:
sendErrorMessage(session, "Unknown message type: " + type);
}
}
@Override
public void afterConnectionClosed(WebSocketSession session, CloseStatus status) {
final String userId = (String) session.getAttributes().get("userId");
final var userActor = getUserActor(userId);
if (userId != null && userActor != null) {
final SpringActorStopContext<UserActor, UserActor.Command> stopContext =
new SpringActorStopContext.Builder<UserActor, UserActor.Command>()
.actorClass(UserActor.class)
.actorId(userId)
.build();
actorSystem.stop(stopContext);
userActors.remove(userId);
}
}
private void handleJoinRoom(String userId, JsonNode payload) {
String roomId = payload.get("roomId").asText();
final var userActor = getUserActor(userId);
if (roomId != null && userActor != null) {
userActor.tell(new JoinRoom(roomId));
}
}
private void handleLeaveRoom(String userId) {
final var userActor = getUserActor(userId);
if (userActor != null) {
userActor.tell(new LeaveRoom());
}
}
private void handleChatMessage(String userId, JsonNode payload) {
final var userActor = getUserActor(userId);
String messageText = payload.get("message").asText();
if (userActor != null && messageText != null) {
userActor.tell(new SendMessage(messageText));
}
}
private SpringActorRef<UserActor.Command> getUserActor(String userId) {
if (userId == null) {
return null;
}
return userActors.get(userId);
}
private void sendErrorMessage(WebSocketSession session, String errorMessage) {
try {
if (session.isOpen()) {
ObjectNode response = objectMapper.createObjectNode();
response.put("type", "error");
response.put("message", errorMessage);
session.sendMessage(new TextMessage(objectMapper.writeValueAsString(response)));
}
} catch (IOException e) {
e.printStackTrace();
}
}
}
Running the Application
Local Cluster Setup
You can run multiple instances of the application locally using the provided cluster-start.sh script:
This will start 3 instances of the application with the following configuration: - Instance 1: HTTP port 8080, Pekko port 2551 - Instance 2: HTTP port 8081, Pekko port 2552 - Instance 3: HTTP port 8082, Pekko port 2553
To stop the cluster:
Docker Deployment
You can also deploy the chat application as a clusterized app using Docker:
# Navigate to the chat example directory
cd example/chat
# Run the init-local-docker.sh script to build and deploy the application
sh init-local-docker.sh
This script will:
- Build the chat application JAR file
- Build a Docker image for the application
- Deploy a 3-node Pekko cluster using Docker Compose
- Each node will be accessible at:
- Node 1: http://localhost:8080
- Node 2: http://localhost:8081
- Node 3: http://localhost:8082
Viewing Logs
To view logs for a specific node:
Stopping the Deployment
To stop the Docker deployment:
The Docker deployment uses the same application code but configures it to run in a containerized environment, making it easier to deploy and scale in production scenarios.
Architecture Benefits
This architecture eliminates the need for third-party middleware by leveraging:
- Built-in message routing between actors
- Natural state management within actors
- Scalability through sharded actors
- Real-time communication via WebSockets
- Fault tolerance provided by the actor system
Key Takeaways
- The actor model provides an effective way to handle real-time communication
- WebSockets combined with actors create an efficient messaging system
